BACKLED M CP, BA-M-CP BLUE G4 24W 12V

EAN: 4062172183437
106,98 € (+ 20% VAT)

You need to register / log in to buy
Sales unit
  • LED chain comprising 40 LED modules connected by flexible cables
Benefits
  • Uniform illumination in narrow channels thanks to Oval Lens Technology
  • PCB and LEDs are protected inside a complete overmolded IP66 housing
  • CRI >80 and 3SDCM
  • Large CCT choice
  • Very long life time and 5 years guarantee
Applications
  • Backlighting of small and/or flat channel letters
  • Backlighting of thin and flat light boxes
  • Permanent outdoor use in enclosed light boxes or channel letters
Family data sheet View downloads

Products

Product Color rendering index Ra Color temperature Luminous flux Data sheet
BackLED M CP, BA-M-CP 865 G4 28,8W 12V ≥80 6500 K 82 lm
BackLED M CP, BA-M-CP 840 G4 28,8W 12V ≥80 4000 K 82 lm
BackLED M CP, BA-M-CP 830 G4 28,8W 12V ≥80 3000 K 78 lm
BackLED M CP, BA-M-CP RED G4 24W 12V ≥80 Red 21,5 lm
BackLED M CP, BA-M-CP 880 G4 28,8W 12V ≥80 8000 K 79 lm

Downloads

Data sheets, brochures and technical information
